15.6 Inch IPS FHD LCD Display Screen 1920×1080 Middle Size
Product Overview
High-performance 15.6-inch industrial LCD display featuring Full HD resolution with IPS technology for superior viewing angles and color reproduction.
Key Specifications
| Application |
Industrial Control |
| Resolution |
1920×1080 pixels |
| Active Area |
344.16×193.59mm |
| Module Dimensions |
363.8×215.9×7.0mm |
| Aspect Ratio |
16:9 |
| Display Mode |
Normally Black |
| Viewing Angle (CR>10) |
89°/89°/89°/89° (Typical) |
| NTSC Color Gamut |
72% (Typical) |
| Brightness |
500cd/m² (Typical), 1000cd/m² (Typical) |
| Interface |
LVDS |
| Operating Temperature |
-20°C to +70°C |
| Storage Temperature |
-30°C to +80°C |
Industrial Features
- Designed for demanding industrial control applications
- Wide operating temperature range for reliable performance
- High brightness options available for various lighting conditions
- IPS technology ensures consistent viewing angles
15.6-Inch Outdoor TFT LCD Display | 1000 Nits High Brightness | Full HD Resolution
Model: JT-15.6IPSFHD
The JT-15.6IPSFHD is a 15.6-inch CTP FHD TFT display module utilizing a silicon TFT active matrix. With a Full HD resolution of 1920×1080 pixels and a high brightness of 1000 nits, this display is engineered for optimal outdoor visibility.
Technical Specifications
Display Type: 15.6-inch color active matrix TFT LCD
Resolution: 1920×1080 pixels (Full HD)
Brightness: 1000 nits
Interface: LVDS
Supply Voltage: +3.3 VDC
Viewing Angle: Wide viewing angle in all directions
Backlight: LED
Compliance: RoHS, Halogen-free, TEO 6.0, ES6.0
Additional Features: Gamma correction, DE only mode
Key Features
High luminance and contrast ratio with low reflection
High-speed response capability
Optimized for multimedia applications
Suitable for demanding outdoor environments
15.6 inch IPS FHD 1920*1080 TFT LCD Display Product Drawing
This display module combines high brightness with excellent image quality, making it ideal for outdoor applications requiring reliable performance in various lighting conditions.
